FABRICATION FACILITIES

Fabrication Facilities

CNC Bending Machine (Make – Faccin)

Top Roll Diameter	660 mm
Pinching Roll Diameter	650 mm
Lateral Roll Diameter	550 mm
Maximum Plate Width	3300 mm
Maximum Thickness	85 mm

Bending Machine (Make – Boldrini)

Dia of Top Roll	650 mm
Max. Thickness	120 mm (Cold Bending)
Max. Width	3000 mm

Bending Machine (Make – Boldrini)

Dia of Top Roll	650 mm
Max. Thickness	120 mm (Cold Bending)
Max. Width	3000 mm

Bending Machine (Make- Schaffer)

Dia of Top Roll	310 mm
Max. Thickness	20 mm (Cold Bending )
Max. Width	3000 mm
Max. Thickness for Prepinching	12 mm

CNC Plasma with OXY Cutting

Effective Cutting Size	3 mtr. wide x 8.5 mtr. long
CNC Controller	Eckelmann, German Made
Nesting Software	Sigma Nest
Max Thickness Cutting (Plasma – MS & SS)	30 mm (Clean Cut)
Max Thickness Cutting (Oxy–MS)	250 mm

CNC Plasma with OXY Cutting

Effective Cutting Size	3 mtr. wide x 8.5 mtr. long
CNC Controller	Eckelmann, German Made
Nesting Software	Sigma Nest
Max Thickness Cutting (Plasma – MS & SS)	30 mm (Clean Cut)
Max Thickness Cutting (Oxy–MS)	250 mm

Painting Booth

Booth Room Dimensions	Long: 17 mtr., Wide: 6.25 mtr., High: 7 mtr.
Emission	Comply with CPCB standard norms, maintaining emission level within the permissible limit of 150 mg/Nm3.
Illumination	Flame-proof illumination, 1000 Lux in the booth

Shot/Grit Blasting Booth/Chamber

Booth/Chamber Dimensions	Long: 17 mtr., Wide: 6.5 mtr., High: 7 mtr.
Emission	Comply with CPCB standard norms, maintaining emission level using a high efficiency cartridge-based RPJ type dust collector, which does not allow dust particles in the environment more than 2 microns.
Abrasive Media Recovery	T-type floor recovery system that allows

Shot/Grit Blasting Booth/Chamber

Controller	Hypertherm
Max Thickness	200mm
Max Width	2200mm

Press Brake Machine

Capacity	175 Tonn
Thickness	8 mm
Width	3000 mm

Shearing Machine

Max Thickness:	8 mm
Maximum Width:	2500 mm

Shearing Machine

Max Thickness:	8 mm
Maximum Width:	2500 mm

Band saw cutting machine

Thermal stress relieving

Vibration stress relieving

200 tonnes single piece handling capacity

We have many other facilities for fabrication specially for stainless steel, duplex steel, alloy steel. These include plasma cutting upto 55mm, 5no.s bending machines, hydro testing facilities upto 200bar,all type of welding (SAW, MIG, MAG, FCAW, SMAW, TIG), qualified welders (for all positions & more than 20 years’ experience, approved from Llyods), stress relieving, normalizing, surface hardening, hydraulic press and all type of NDT facilities ( MPT, DPT, UT, RT, NDT Level-2 engineers).
